Features
• Highly flexible CAT5e data cable down to -40 °C
• S/UTP ( braided shielding + unshielded twisted pairs )
• Very robust TPE jacket
• EtherSound up to 50 m
• Halogen-free and Flame retardant
Applications
• Network cable for mobile applications and drum storage
• Better to use on stage or outdoor events
• Use for data system technology
Cable Colour
• Black
• Blue
Technical Data
|
|
Jacket, diameter
|
TPE 6.4 mm
|
AWG
|
26
|
No. of inner conductors
|
4 x 2 x 0.15 mm²
|
Copper strand per conductor
|
19 x 0.10 mm
|
Conductor insulation
|
HDPE
|
Shielding
|
Braided shielding
with 128 x 0.12 mm
|
Shielding factor
|
90 %
|
Temperature range
|
min. -40 °C
|
Temperature range
|
max. +85 °C
|
Packaging
|
100/300 m roll
|
|
|
Electrical Data
|
|
Capac. cond./cond. per 1 m
|
45 pF
|
Capac. cond./shield. per 1 m
|
70 pF
|
Cond. resistance per 1 m
|
122 mΩ
|
Shield. resistance per 1 m
|
37 mΩ
|
